EPS Expanded Polystyrene Machine Automatic 7400x3000x4500mm

EPS Expanded Polystyrene Machine Automatic 7400x3000x4500mm
Features Gallery Product Description Request A Quote
Raw Material: EPS
Warranty Period: 1year
Voltage: AC380V 50Hz
Origin: Zhejiang CHINA
Type: Automatic
High Light:

EPS expanded polystyrene machine


Automatic expanded polystyrene machine


4500mm eps preexpander

Basic Infomation
Place of Origin: CHINA
Brand Name: PIN SHENG
Certification: -
Model Number: Customization
Payment & Shipping Terms
Delivery Time: 6-10days
Payment Terms: T/T LC
Product Description

High Accuracy eps polystyrene expander machine with eps beads for sale
Material weight measure section takes special measuring controlling device and loading device ,they are controlled by PLC and HMI ,the amount can be controlled accurately .
Steam system:Steam pressure reducer and angle valve to contorl steam.
Fillng system:Set filling weight in HMI and electronic weighing filling to realize silling accurately and automatically .
Material level control:Adopts laser sensor to control the expansion level.
Temperature control:The temperature sensor and compressedair proprtional valve maintains accurate expansion temperature which is suitable for high density expansion ,resulting in less broken beads



Item Unit PSPEB-A130 PSPEB-A150
Expansion Chamber Diameter mm ∅1300 ∅150
Volume 2.4 5.4
Useable volume 1.6 4.5
Steam Inlet mm ∅65 ∅100
Consumption kg/cycle 10-12 18-20
Pressure Mpa 0.6-0.8 0.6-0.8
Compressed air Inlet mm ∅40 ∅50
Consumption m³/cycle 0.7-0.9 0.5-0.8
Pressure Mpa 0.6-0.8 0.6-0.8
Drainage Drainage port mm ∅100 ∅150
Connected load Installing power Kw 21 40
Density g/L 12-30 12-30
Out side dimensions % ±2 ±2
Material conveying mm ∅150 ∅200
Overall size (LXWXH) mm 7400X3000X4500 11000X2850X6100
Weight kg 4250 8000
Room height required mm 6000 7000
Productivity kg/h 12g/L 530 12g/L 1000
kg/h 15g/L 670 15g/L 1300
kg/h 20g/L 920 18g/L 1800
kg/h 30g/L 1220 25g/L 2400

EPS Expanded Polystyrene Machine Automatic 7400x3000x4500mm 0



EPS Expanded Polystyrene Machine Automatic 7400x3000x4500mm 1


1. Where is your factory located?
We have 2 production plant, one plant locates in Hangzhou which professionally producing EPS/EPP/ETPU machine. Another factory locates in Jiangsu Provide which producing EPS/EPP/ETPU mould. Both two factories are pretty close to the Shanghai port for easiest transportation.


2. Do you have detailed and professional installation manual?
We will provide very detailed installation manuals and videos, and the service until you are satisfied


3. Are you a trading company or a manufacturer?
We are manufacturer.


4. How long is your delivery time?
Normally delivery time is 30~45 days.


5. How many years have your company made this kind of equipment?
More than 10 years.


6. Can I only buy some spare parts from you?
Yes, we also provide all kinds of spare parts that relatives to our machine.


7. How do you pack the equipment?
We will strengthen and protect the equipment to ensure that they will not be damaged during transportation


8. Can you send your staff to install the equipment for us?
Under normal conditions, it is possible. Now it is an epidemic situation.
We will try our best to assist in case wecannot send technician in time. We will also conduct video connections with guests to teach them to install them in place.


9. Can you can design the equipment according to our size?
Yes, it is acceptable


10. How many production lines in your factory?
We have total 10 production line.
