Ploystyrene EPS Pre Expander Machine Batch With Fluidized Bed

1
MOQ
negotiation
Price
Ploystyrene EPS Pre Expander Machine Batch With Fluidized Bed
Features Gallery Product Description Request A Quote
Features
Specifications
Raw Material: EPS
Voltage: AC380V 50Hz
Warranty Period: 1year
Origin: Zhejiang CHINA
Type: Batch Pre Expander
Color: Customization
Port: SHANGHAI/NINGBO
Operation: Automatic
High Light:

Ploystyrene eps pre expander machine

,

380V eps pre expander machine

,

EPS preexpander

Basic Infomation
Place of Origin: CHINA
Brand Name: PIN SHENG
Model Number: PSPEB-A130
Payment & Shipping Terms
Delivery Time: 6-10days
Payment Terms: T/T LC
Product Description

PSPEB-Accurate with Fluidized Bed Ploystyrene Pre Expander Equipment

Using weighing controller and load unit, Mitsubishi FX5U series PLC precise control, particle uniformity and less energy consumption
1. All process including filling, expanding, sieving, delumping and conveying to silos are done automatically.
2. With primary and secondary expansion device to get density of 8-30g/l
3. Fist filling is controlled by frequency converter
4. With power-off protection device
Item Unit PSPEB-A130 PSPEB-A150
Expansion Chamber Diameter mm ∅1300 ∅150
Volume 2.4 5.4
Useable volume 1.6 4.5
Steam Inlet mm ∅65 ∅100
Consumption kg/cycle 10-12 18-20
Pressure Mpa 0.6-0.8 0.6-0.8
Compressed air Inlet mm ∅40 ∅50
Consumption m³/cycle 0.7-0.9 0.5-0.8
Pressure Mpa 0.6-0.8 0.6-0.8
Drainage Drainage port mm ∅100 ∅150
Connected load Installing power Kw 21 40
Density g/L 12-30 12-30
Out side dimensions % ±2 ±2
Material conveying mm ∅150 ∅200
Overall size (LXWXH) mm 7400X3000X4500 11000X2850X6100
Weight kg 4250 8000
Room height required mm 6000 7000
Productivity kg/h 12g/L 530 12g/L 1000
kg/h 15g/L 670 15g/L 1300
kg/h 20g/L 920 18g/L 1800
kg/h 30g/L 1220 25g/L 2400

Ploystyrene EPS Pre Expander Machine Batch With Fluidized Bed 0


Ploystyrene EPS Pre Expander Machine Batch With Fluidized Bed 1

FAQ

1. Where is your factory located?
We have 2 production plant, one plant locates in Hangzhou which professionally producing EPS/EPP/ETPU machine. Another factory locates in Jiangsu Provide which producing EPS/EPP/ETPU mould. Both two factories are pretty close to the Shanghai port for easiest transportation.



2. Do you have detailed and professional installation manual?
We will provide very detailed installation manuals and videos, and the service until you are satisfied



3. Are you a trading company or a manufacturer?
We are manufacturer.



4. How long is your delivery time?
Normally delivery time is 30~45 days.



5. How many years have your company made this kind of equipment?
More than 10 years.



6. Can I only buy some spare parts from you?
Yes, we also provide all kinds of spare parts that relatives to our machine.



7. How do you pack the equipment?
We will strengthen and protect the equipment to ensure that they will not be damaged during transportation



8. Can you send your staff to install the equipment for us?
Under normal conditions, it is possible. Now it is an epidemic situation.
We will try our best to assist in case wecannot send technician in time. We will also conduct video connections with guests to teach them to install them in place.



9. Can you can design the equipment according to our size?
Yes, it is acceptable



10. How many production lines in your factory?
We have total 10 production line.
