Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam

1
MOQ
negotiation
Price
Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam
Features Gallery Product Description Request A Quote
Features
Specifications
Steam Pressure: 0.6-0.8 Mpa
Expansion Chamber Volume: 2.2m3
Port: SHANGHAI/NINGBO
Warranty: 1 Year
Connected Load: 15kw
Weight: 1800
Drainage: 20mm
Highlight:

Sturdy EPS Pre Expander

,

Precision EPS Pre Expander

,

Expanded Polystyrene Foam EPS Pre Expander
Basic Infomation
Place of Origin: Zhejiang China
Brand Name: PINSHENG
Model Number: PSPEC120
Payment & Shipping Terms
Delivery Time: 6-10days
Payment Terms: T/T LC
Supply Ability: 10pcs per month
Product Description
The EPS (Expanded Polystyrene) pre-expander machine is a device used in the manufacturing process of expanded polystyrene foam products.


Precision Measurement System: Equipped with a precise measurement system, it ensures accurate feeding, thereby guaranteeing the quality of the pre-expanded EPS beads. This is crucial for maintaining the stability and consistency of the final EPS product's performance.





Sturdy Construction and High Thermal Efficiency: The drum of the EPS Pre Expander is typically made of stainless steel, providing a sturdy structure. It utilizes high-quality closed-system constant-pressure foaming technology, which enhances the thermal efficiency of the foaming process, resulting in superior EPS products.



Item Unit PSPEC90 PSPEC120
Expansion Chamber Diameter mm Ф900 Ф1200
Volume m3 1.2 2.2
Useable volume m3 0.8 1.5
Steam Inlet mm Ф25 Ф40
Consumption Kg/cycle 100-150 150-200
Pressure Mpa 0.6-0.8 0.6-0.8
Compressed air Inlet mm Ф25 Ф25
Pressure Mpa 0.6-0.8 0.6-0.8
Drainage Condensation mm Ф20 Ф20
Connected load Instaling power Kw 10 15
Density First expansion g/L 12-30 14-30
Second expansion g/L 8-11 8-13
Overall size (LXWXH) mm 4700X3000X3200 4900X4700X3200
Weight kg 1500 1800
Room height required mm 5000 5000
Productivity 15g/L kg/h 150 250
20g/L kg/h 200 300
25g/L kg/h 250 410
30g/L kg/h 300 500

Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam 0Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam 1Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam 2Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam 3Precision Sturdy EPS Pre Expander For Expanded Polystyrene Foam 4
