Home /Products/EPS Shape Moulding Machine/Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers

Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers

1
MOQ
negotiation
Price
Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers
Features Gallery Product Description Request A Quote
Features
Specifications
Processing Type: Foaming Machine
Cycle Time: 60-140S
Room Height Required: 5m
Origin: Zhejiang CHINA
Warranty Period: 1year
Max Product Height: 1850 Mm
Machine Dimension: 4590x2900x4300 Mm
Foam Density: 8-65kg/m3
Highlight:

Save Energy EPS Shape Moulding Machine

,

Customizable EPS Shape Moulding Machine

,

Molding Chambers EPS Shape Moulding Machine
Basic Infomation
Place of Origin: Zhejiang China
Brand Name: PINSHENG
Model Number: PSSM 200F
Payment & Shipping Terms
Delivery Time: 6-10days
Payment Terms: T/T LC
Supply Ability: 10pcs per month
Product Description
Molding Chamber: Once inside the machine, the pre-expanded EPS beads are transferred to the molding chamber. The molding chamber contains a mold or tooling that defines the desired shape and size of the final EPS foam product. The expanded beads are placed into the mold cavity.
Closing and Pressing: After the beads are in the mold cavity, the molding chamber is closed, and pressure is applied to compress the beads. This compression allows the beads to fuse together, forming a solid and uniform structure.
Cooling: After the pressing stage, the mold is cooled to solidify the EPS foam. Cooling can be achieved through the circulation of chilled water or other cooling methods. Proper cooling ensures that the molded foam retains its shape and stability.
Mold Opening and Ejection: Once the EPS foam has cooled and solidified, the mold is opened, and the finished product is ejected from the machine. The mold may have ejector pins or other mechanisms to facilitate the removal of the molded part.

Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 0Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 1Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 2Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 3Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 4Save Energy Customizable EPS Shape Moulding Machine With Steam And Molding Chambers 5

Tag:

Automatic EPS Shape Moulding Machine

20kw EPS Shape Moulding Machine

Automatic machine eps
