Home /Products/EPS Shape Moulding Machine/Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient

Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient

1
MOQ
negotiation
Price
Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient
Features Gallery Product Description Request A Quote
Features
Specifications
Voltage: AC380V 50Hz
Warranty Period: 1 Year
Power: 10.6-20Kw
Distance Of Opening Mold: 150-1500mm
Room Height Required: 5m
Color: Customization
Highlight:

Polystyrene Eps Shape Molding Machine

,

AC380V Eps Shape Molding Machine

,

AC380V Polystyrene Moulding Machine
Basic Infomation
Place of Origin: CHINA
Brand Name: PIN SHENG
Certification: -
Model Number: PSSM100-200
Payment & Shipping Terms
Delivery Time: 6-10days
Payment Terms: T/T LC
Product Description

CPIN SHENG EPS SHAPE MOLDING MACHINE POLYSTYRENE MOULDING MACHINE



Item Unit PSSM140B PSSM160B PSSM170B PSSM180B PSSM200B
Mould Dimension mm 1400X1200 1600X1400 1700X1500 1800X1600 2000X1800
Max Product Dimension mm 1250X1050X350 1450X1350X350 1550X1350X350 1650X1450X350 1850X1650X350
Stroke mm 170-1420 170-1420 170-1420 120-1370 40-1290
Steam Inlet mm DN100 DN100 DN100 DN100 DN100
Steam Consumption t/t (10-15t)Steam of 1t Material
Cooling Water inlet mm DN80 DN80 DN80 DN80 DN100
Cooling Water
Consumption		 kg/cycle 55-150 60-180 70-190 90-200 100-220
Compressed Air Inlet mm DN40 DN40 DN50 DN50 DN50
Compressed Air
Consumption		 m³/cycle 1.8 2 2.2 2.4 2.6
Vacuum Pump
Capacity		 m³/h 230 230 280 280 280
Drainage Port mm DN150 DN150 DN150 DN150 DN150
Connected Load kw 13 17 17 17 20
Outside Dimension mm 4600X2300X3800 4600X2500X4000 4600X2600X4100 4600X2700X4200 4600X2900X4400
Weight kg 5000 6000 6500 7000 7500
Cycle Time s 60-120 70-160 80-170 80-180 90-180



Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient 0Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient 1Eps Automatic FAST Exchange mould Shape Package Foam Adjustable Moulding Vacuum Machine WITH Energy Efficient 2



Tag:

Automatic EPS Shape Moulding Machine

20kw EPS Shape Moulding Machine

Automatic machine eps
